Choose your model Choose where your part is located Choose which part drawing you want to see
| Product | Stock code | Availability | Del. date | Price |
|---|
Position: Gasket
| Product | Remark1 | ||||
|---|---|---|---|---|---|
| GASKET ARMR ARTICULATING |
|
|
Position: 1
| Product | Remark1 | ||||
|---|---|---|---|---|---|
| ARMR BRACKET ASSY LEFT |
|
|
|||
| ARMR BRACK ASSY WIDE LEFT |
|
|
Position: 2
| Product | Remark1 | ||||
|---|---|---|---|---|---|
| ARMR BRACKET LEFT v.2 |
|
|
|||
| ARMR BRACKET WIDE LEFT v. 2 |
|
|
Position: 7
| Product | Remark1 | ||||
|---|---|---|---|---|---|
| Spring plunger GN 615-M8-KSN |
|
|
Position: 9
| Product | Remark1 | ||||
|---|---|---|---|---|---|
| COVER ARMREST LEFT |
|
|
Position: 11
| Product | Remark1 | ||||
|---|---|---|---|---|---|
| CUP SPRING 28 X 14.2 X 1 |
|
|
Position: 13
| Product | Remark1 | ||||
|---|---|---|---|---|---|
| BOLT MC6S 6x10 fzb ISO 4762 |
|
Center screw for old type of armrest |
|
Position: 14
| Product | Remark1 | ||||
|---|---|---|---|---|---|
| SHAFT ARMREST ADJUSTMENT |
|
|
Position: 15
| Product | Remark1 | ||||
|---|---|---|---|---|---|
| TIE BAR ARMREST |
|
|
|||
| TIE BAR ARMREST WIDE |
|
|
Position: 16
| Product | Remark1 | ||||
|---|---|---|---|---|---|
| Washer, BRB, 6.4x12x1,5 |
|
|
Position: 17
| Product | Remark1 | ||||
|---|---|---|---|---|---|
| LOCK NUT M6 FZB |
|
|
Position: 18
| Product | Remark1 | ||||
|---|---|---|---|---|---|
| SCREW M6 |
|
|
|||
| SCREW M6 CORPUS 3G |
|
Pointed screw, should only be used on the first version of the armrest. |
|
